2026 Ford F-150 Lightning STX 4WD SuperCrew 5.5' Box

STX 4WD SuperCrew 5.5' Box

Change Trim

Price Info

Price with options: $63,345

MSRP: $63,345

Base Invoice: $60,811

Body Style

Crew Cab Pickup - Short Bed

MPG

City: 0 - Hwy: 0

Select a color
Ford F-150 Lightning STX 4WD SuperCrew 5.5' Box
Select an image to view:

Quick Search

Choose Your Ford F-150 Lightning STX 4WD SuperCrew 5.5' Box Options

Price With Options:

$63,345

2026 Ford F-150 Lightning Pros

The F-150 Lightning carries over into 2026 and deletes the XLT trim while at the same time adding a new STX trim which adds more attitude to the F-150 lightning. This new trim includes 18-inch matte black painted aluminum wheels, a new front grille molded in color and grabber blue accents, off-road-style running boards, as well as the STX logo on the bedside and hood.

2026 Ford F-150 Lightning Model Highlights

The F-150 Lightning has to be many things to many people, from work truck to cruiser, off-road vehicle to boat hauler, there is an F-150 Lightning for virtually every task. As a result, the lineup is diverse.

Rather than talking about how many liters the engine has, we talk about?batteries.?Every new F-150 Lightning pickup has all-wheel?drive and two electric motors.?The motors also make a considerable amount of power and?torque.?For the 2026 model the standard battery has a range of 230 miles, and the extended-range option runs for up to 320 miles on a single full?charge. In terms of charging capabilities, the Lightning includes a mobile power cord equipped with a North American Charging Standard (NACS) adapter. This adds compatibility with a broader range of charging stations, including Tesla's Supercharger network, enhancing the convenience of charging options for owners.?The standard battery makes 452 horsepower and still a very impressive 775 lb.-ft of?torque.?The two 3-phase fixed magnet AC electric motors in the extended-range option put out a whopping 580 horsepower and 775 lb.-ft of?torque. Charging at home is easy with the 80-amp Ford Charge Station Pro, it powers up to 30 miles of charge per hour to provide a full charge overnight. Ford claims the two inboard motors provide a faster acceleration than any other F-150 Lightning yet with 0-60 mph in the mid four second range.

The F-150 Lightning trims include the Pro, which is available as a fleet only trim, the newly added STX, Flash, Lariat, and Platinum with all-wheel drive, a SuperCrew Cab and a 5.5-foot box. Advanced technology includes powerful charging solutions, Ford Pass Integration, Ford Connected Charge Station, and the Ford Charge Station Pro. The addition of Ford Intelligent Backup Power also means you can seamlessly connect to your house and power it up with the push of a button. Ford estimates that the Intelligent Backup Power can provide full-home power for up to three days on a fully charged battery. Another unique feature of the F-150 Lightning is the Pro Power Onboard which offers up to 9.6 kw power through the 120V outlets provided, four in the front, two in the cab and four in the bed.

Another interesting feature on the F-150 Lightning is the Intelligent Range system which calculates the distance you can travel while factoring in weather, traffic, grade, payload, and towing weights. The F-150 Lightning has a towing capacity of up to 10,000 lbs. when equipped with Max trailer pro package. The Onboard scale, Pro Trailer Hitch Assist, Smart Hitch, Pro Trailer Backup Assist and Trailer Reverse Guidance are all available to make towing a trailer as easy as turning a knob.

Since the F-150 Lightning is still designed to be a work truck several features were created to make it easier to work from anywhere. 2026 models include Pro Trailer Hitch Assist automatically controls steering, throttle and brake inputs to make hitching trailers easier. The Tailgate Work Surface is designed with composite materials, clamp pockets, tailgate tie downs and a flat surface for writing, measuring, and cutting. There is a ruler, a mobile device holder, a cupholder and small item storage.

With the removal of the engine the F-150 Lightning freed up space, allowing for the inclusion of what Ford is calling a Mega Power Frunk. The hood opens creating a storage space with 14.1 cubic feet of cargo capacity. With 400-lbs. of payload capacity Ford says is can carry eight 50-Ib bags of concrete mix. It also includes a cargo management system with grocery hooks, tie-downs, a cargo net, and multi-function lid divider.

The newly added STX takes the XLT's throne this year, adding new 18-inch matte black painted aluminum wheels, a new front grille molded in colour with grabber blue accents, which match grabber blue elements in the interior, STX graphics on the side of the bed and the hood, and unique looking off-road style running boards which complement the overall more rugged look. Additional standard features include LED headlights and daytime running lights, easy-lift tailgate, a 6-speaker sound system, a 12-inch touchscreen, 8 120v outlets, tailgate lift voice activated navigation, and a bunch of ADAS features including lane keeping assist and cruise control. Also, standard and new for 2026 is the new 123 kWh extended range battery.

The Flash trim gets 20-inch wheels, LED pickup box lights 10-way power front seats, 15.5-inch infotainment screen, Ford's Blue Cruise hands-free driving system, intelligent access with push-button start, a premium 8-speaker sound system, keyless entry- keypad, power tailgate, wireless charger, Ford Bluecruise and surround cameras.

The Lariat adds a dual panel moonroof, illuminated running boards, power open and close tailgate, a retractable rear step, heated and ventilated front seats, power tilt/telescoping steering column with memory, memory driver seat, 8-speakers, wireless charging, 15-inch touchscreen, and a garage door transmitter.

The Platinum features 22-inch wheels, a power sunroof, a skid plate, 8-way power massaging front leather seats, heated rear seats, 14-speaker premium stereo, hill descent control, electronic selectable differential, and a heated steering wheel.

Safety is important and the F-150 Lightning includes active lane departure, blind spot warning, lane-Keeping System, forward and rear collision mitigation, post-crash alert system, post-collision braking, curve control, pedestrian detection, and a driver attention alert.

2026 Ford F-150 Lightning Model News

The electric truck revolution is still ongoing, and Ford is committed to ensuring that its F-150 Lightning remains a leader in the market. It continues to be one of their top-selling electric vehicles, encouraging Ford to put their best foot forward with the 2026 model, even though the ICE segment still takes the cake for most sales in the U.S. The F-150 Lightning competes with the GMC Hummer EV, and Rivian R1T in the full-sized truck category. Ford is clearly pushing forward its innovative technology and latest ideas with the F-150 Lightning, offering plenty of options not available anywhere else in this class. At the same time, the F-150 Lightning continues to excel at traditional truck tasks, with a best-in-class towing capacity of over 10,000 pounds when properly equipped.

2026 Ford F-150 Lightning Value Writeup

Towing capacity; available in a variety of trims; all-electric; rugged durability

Brakes
4-Wheel Brake ABS System
4-Wheel Brake ABS System (Second Line)
4-Wheel Disc Brake Type
Yes Disc - Front (Yes or )
Yes Disc - Rear (Yes or )
Drum - Rear (Yes or )
14 Front Brake Rotor Diam x Thickness (in)
13.8 Rear Brake Rotor Diam x Thickness (in)
Rear Drum Diam x Width (in)
Engine
None Engine Oil Cooler
99U Engine Order Code
Electric Engine Type
536 SAE Net Horsepower @ RPM
775 SAE Net Torque @ RPM
Mileage
300.0 Battery Range (mi)
- TBD - EPA MPG Equivalent - City
- TBD - EPA MPG Equivalent - Combined
- TBD - EPA MPG Equivalent - Hwy
Suspension
3900 Axle Capacity - Front (lbs)
4150 Axle Capacity - Rear (lbs)
9.61 Axle Ratio (:1) - Front
9.61 Axle Ratio (:1) - Rear
Independent Axle Type - Front
Independent Axle Type - Rear
3940 Spring Capacity - Front (lbs)
4950 Spring Capacity - Rear (lbs)
Double Wishbone Suspension Type - Front
Trailing Arm Suspension Type - Rear
Transmission
All Wheel Drive Drivetrain
Automatic Trans Description Cont.
Trans Description Cont. Again
44L Trans Order Code
No Trans PTO Access
1 Trans Type
None Transfer Case Model
No Transfer Case Power Take Off
Vehicle
123.0 Usable/net Traction Battery Capacity (kWh)
Weight Information
6361 Base Curb Weight (lbs)
3253 Curb Weight - Front (lbs)
3108 Curb Weight - Rear (lbs)
3940 Gross Axle Wt Rating - Front (lbs)
4950 Gross Axle Wt Rating - Rear (lbs)
15000 Gross Combined Wt Rating (lbs)
8550 Gross Vehicle Weight Rating Cap (lbs)
MECHANICAL
Engine: Dual eMotor - Extended Range Battery -inc: 48A single onboard charging, level 2 peak charging rate of 11.5kW and 123 kWh usable capacity extended range battery
Transmission: Single-Speed
GVWR: 8,550 lbs
Full-Time All-Wheel
Driver Selectable Rear Locking Differential
9.61 Axle Ratio
Battery w/Run Down Protection
Class IV Towing Equipment -inc: Hitch and Trailer Sway Control
Trailer Wiring Harness
2189# Maximum Payload
HD Gas-Pressurized Front Shock Absorbers and Gas-Pressurized Rear Shock Absorbers
Front And Rear Anti-Roll Bars
Electric Power-Assist Speed-Sensing Steering
Permanent Locking Hubs
Double Wishbone Front Suspension w/Coil Springs
Trailing Arm Rear Suspension w/Coil Springs
Regenerative 4-Wheel Disc Brakes w/4-Wheel ABS, Front And Rear Vented Discs, Brake Assist, Hill Descent Control, Hill Hold Control and Electric Parking Brake
Lithium Ion (li-Ion) Traction Battery w/14.6 Hrs Charge Time @ 220/240V and2.033 Hrs Charge Time @ 440V
EXTERIOR
Wheels: 18" Matte Black Painted Aluminum
Tires: 275/65R18 A/T
Regular Box Style
Tire Mobility Kit
Paint w/Decal
Black Front Bumper w/Black Rub Strip/Fascia Accent and 2 Tow Hooks
Black Rear Step Bumper
Black Side Windows Trim
Black Door Handles
Black Power Heated Side Mirrors w/Manual Folding and Turn Signal Indicator
Fixed Rear Window w/Defroster
Deep Tinted Glass
Variable Intermittent Wipers
Aluminum Panels
Running Boards
Body-Colored Grille
Tailgate Rear Cargo Access
Tailgate/Rear Door Lock Included w/Power Door Locks
Integrated Storage
Ford Co-Pilot360 - Autolamp Auto On/Off Projector Beam Led Low/High Beam Directionally Adaptive Auto High-Beam Daytime Running Lights Preference Setting Headlamps w/Delay-Off
Cargo Lamp w/High Mount Stop Light
LED Brakelights
Headlights-Automatic Highbeams
Perimeter/Approach Lights
ENTERTAINMENT
Radio: FM Stereo/SiriusXM w/360L w/6 Speakers -inc: Note: trial length: A 3-month trial subscription is included for all new SiriusXM-equipped Ford vehicles SiriusXM w/360L trial Subscription: Service will automatically stop at the end of your trial subscription period unless you decide to continue service, Trial is non-transferable, If you do not wish to enjoy your trial, you can cancel by calling the number below, All SiriusXM services require a subscription, each sold separately by SiriusXM after the trial period, Service subject to the SiriusXM customer agreement and privacy policy, visit siriusxm.com for complete terms and how to cancel which includes online methods or calling 1-866-635-2349, Some services and features are subject to device capabilities and location availability, Satellite service not available in AK and HI, Certain features and/or content may not be available in vehicles w/SiriusXM w/360L unless an active data connection is enabled in the vehicle, Content varies by SiriusXM subscription plan, All fees, content and features are subject to change, SiriusXM and related logos are trademarks of Sirius XM Radio Inc, and its respective subsidiaries
Radio w/Seek-Scan, Clock, Speed Compensated Volume Control, Steering Wheel Controls, Voice Activation, Radio Data System and External Memory Control
6 Speakers
Streaming Audio
Fixed Antenna
2 LCD Monitors In The Front
Real-Time Traffic Display
INTERIOR
Cloth Heated Front Seats -inc: STX accents, 8-way power driver w/power lumbar and manual passenger lumbar
Driver Seat
Passenger Seat
60-40 Folding Split-Bench Front Facing Fold-Up Cushion Rear Seat
Manual Tilt/Telescoping Steering Column
Gauges -inc: Speedometer, Odometer, Engine Coolant Temp, Traction Battery Level, Power/Regen, Traction Battery Temperature, Trip Odometer and Trip Computer
Power Rear Windows
Heated Leatherette Steering Wheel
Front Cupholder
Rear Cupholder
3 12V DC Power Outlets
Compass
Proximity Key For Push Button Start Only
Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry and Panic Button
Cruise Control w/Steering Wheel Controls
Voice Activated Dual Zone Front Automatic Air Conditioning
HVAC -inc: Underseat Ducts and Console Ducts
Locking Glove Box
Driver Foot Rest
Full Cloth Headliner
Urethane Gear Shifter Material
Interior Trim -inc: Metal-Look Instrument Panel Insert, Cabback Insulator, Metal-Look Door Panel Insert and Chrome/Metal-Look Interior Accents
Day-Night Auto-Dimming Rearview Mirror
Driver And Passenger Visor Vanity Mirrors
Full Floor Console w/Locking Storage, Mini Overhead Console w/Storage, 3 12V DC Power Outlets and 6 Interior 120V AC Power Outlets
Fade-To-Off Interior Lighting
Front And Rear Map Lights
Plastic Floor Trim
Full Carpet Floor Covering -inc: Carpet Front And Rear Floor Mats
Cargo Area Concealed Storage
Cargo Features -inc: Tire Mobility Kit
Cab Mounted Cargo And Cargo Space Lights
Smart Device Remote Engine Start
Ford Connectivity Package (1-Year Included) -inc: unlimited Wi-Fi hotspot, connected navigation, EV trip planner, pinch-to-zoom capability, live traffic, predictive destinations and route guidance, audio and video streaming, voice assistant and entertainment (karaoke), Included for one-year from warranty start date, Requires activation via Ford app w/credit card authorization; customer may cancel at any time, Evolving technology/cellular networks/vehicle capability may limit functionality and prevent operation of connected features, Ford may temporarily slow data speeds if such data usage reaches or exceeds 50GB within a billing cycle or due to network limitations, If a customer uses more than 50% of their data usage in a roaming country during a 60-day period, Ford may remove or limit the customer's data plan
SYNC 4 w/Enhanced Voice Recognition -inc: 12" center display, information on demand panel, wireless phone connection, cloud connected, AppLink w/App catalog, 911 Assist, wireless Apple CarPlay and Android Auto compatibility, digital owners manual and conversational voice command recognition
Instrument Panel Bin, Dashboard Storage, Interior Concealed Storage, Driver / Passenger And Rear Door Bins and 2nd Row Underseat Storage
Power 1st Row Windows w/Driver And Passenger 1-Touch Up/Down
Delayed Accessory Power
Power Door Locks w/Autolock Feature
Power Adjustable Pedals
Driver Information Center
Trip Computer
Outside Temp Gauge
Digital Appearance
Manual Adjustable Front Head Restraints and Manual Adjustable Rear Head Restraints
Front Center Armrest
Seats w/Cloth Back Material
2 Seatback Storage Pockets
Perimeter Alarm
3 12V DC Power Outlets and 6 Interior 120V AC Power Outlets
SAFETY
AdvanceTrac w/Roll Stability Control Electronic Stability Control (ESC) And Roll Stability Control (RSC)
ABS And Driveline Traction Control
Side Impact Beams
Dual Stage Driver And Passenger Seat-Mounted Side Airbags
PCA with AEB and Intersection Assist
Cross-Traffic Alert with Reverse Brake Assist
Ford Co-Pilot360 - Lane-Keeping Assist Lane Keeping Assist
Ford Co-Pilot360 - Lane-Keeping Assist Lane Departure Warning
Collision Mitigation-Front
Driver Monitoring-Alert
Rear Parking Sensors
BLIS with Trailer Tow Coverage Blind Spot
Aerial View Camera System
Tire Specific Low Tire Pressure Warning
Dual Stage Driver And Passenger Front Airbags
Safety Canopy System Curtain 1st And 2nd Row Airbags
Airbag Occupancy Sensor
Driver And Passenger Knee Airbag
Mykey System -inc: Top Speed Limiter, Audio Volume Limiter, Early Low Fuel Warning, Programmable Sound Chimes and Beltminder w/Audio Mute
Rear Child Safety Locks
Outboard Front Lap And Shoulder Safety Belts -inc: Rear Center 3 Point, Height Adjusters and Pretensioners
Reverse Camera Back-Up Camera
Front Camera w/Washer
Cargo Bed Camera
Left Side Camera
Right Side Camera
